جزئیات محصول:
پرداخت:
|
| مواد عایق: | XLPE | تایپ کنید: | ولتاژ پایین |
|---|---|---|---|
| برنامه: | صنعتی | مواد هادی: | مس |
| ژاکت: | پی وی سی | اندازه: | 16 میلی متر مربع |
| زره: | نوار فولادی | گارانتی: | 2 سال |
| ولتاژ نامی: | 0.6/1kV | بسته بندی: | طبل |
| استاندارد: | IEC60502-1 | نوع هادی: | هادی رشته ای |
| رنگ: | مشکی | ولتاژ تست: | 3.5 کیلو ولت / 5 دقیقه |
| نمونه: | موجود است | بندر: | بندر شانگهای |
| شرکت: | گروه شنگوا | نام تجاری: | کابل Sh |
| برجسته کردن: | 26/35kV 3-core XLPE power cable,XLPE insulated industrial power cable,3-core energy supply cable,XLPE insulated industrial power cable,3-core energy supply cable |
||
|
Nom. Cross-Section
|
Insulation Thickness
|
Approx. Overall Diameter (O.D.)
|
Approx. Weight
|
Current Rating in Air (A)
|
|---|---|---|---|---|
|
3x95 mm²
|
10.5 mm
|
88.0 mm
|
8630 kg/km
|
280
|
|
3x150 mm²
|
10.5 mm
|
95.0 mm
|
11017 kg/km
|
360
|
|
3x240 mm²
|
10.5 mm
|
103.0 mm
|
14427 kg/km
|
470
|
Standards
IEC 60332-1 Tests on electric and optical fibre cables under fire conditions.
IEC 60502-1 Power cables with extruded insulation and their accessories for rated voltages of 1 kV and 3 kV.
IEC 60754 Test on gases evolved during combustion of materials from cables.
IEC 61034 Measurement of smoke density of cables burning under defined conditions.
BS 7870-3 LV and MV polymeric insulated cables for use by distribution and generation utilities.
DIN VDE0276-603 Power cables - Part 603: Distribution cables of rated voltage 0,6/1 kV.
ANSI/NEMA WC 70-2009/ICEAS-95-658 Power Cables Rated 2000 Volts or Less for the Distribution of Electrical Energy.
AS/NZS 4026:2008 Electric cables - For underground residential distribution systems Standards Australia.
AS/NZS 4961:2003 Electric cables - Polymeric insulated - For distribution and service applications.
AS/NZS 5000.1:2005 Electric cables - Polymeric insulated - For working voltages up to and including 0.6/1 (1.2) kV.
Other Equivalent standards for PVC insulated power cable.
Rated voltage: 0.6 / 1 kV
Maximum Conductor Temperature: under normal (90 OC), emergency (130OC) or short circuit no more than 5 s (250℃) conditions.
Min. Ambient Temp. 0 OC, after installation and only when cable is in a fixed position
Min. Bending Radius: 12 x cable O.D
1. Shipping: By sea or air due to heavy weight. Samples will be send by DHL, Fedex. etc
2. Payment: We accept T/T, L/C , just choose what you like
3. Delivery time: Generally 7~10 working days upon receipt deposit. According to the quantity.
4. MOQ: Generally our MOQ is 1000meters. samples below 20 centimeter can be provided freely
Armored or unarmored. If armor, the armor type & material
The Requirement of Sheath
Length of Cable & Packing Requirement
Other Requirement
Only high quality XLPE insulation material are used.
Massive production offer you competitive price.
Free sample and OEM.
Packing & Shipping
We are capable of meeting the most strict delivery schedules according to per purchase order. Meeting the deadline is always the top priority as any delay in the delivery of cable can contribute to overall project delay and cost overrun.
Cable is supplied in wooden reels, corrugated boxes and coils. Cable ends are sealed with BOPP self adhesive tape and non-hygroscopic sealing caps to protect the cable ends from moisture. The required marking shall be printed with a weather-proof material on the outsides of drum according to customer's requirement.
After the well packed cable drums sent to Sea Port, they are loaded into 20 FT container or 40 FT container. All cable drum are firmly fixed by safety belt to make sure, no movement during the sea freight.
The size of the container is chosed according to weight of total loaded goods or as per the client's requirement.
Our Services
♦ We are the one of biggest manufacture of electric wire and power cable in southwest of China and has more than 20 years producing and marketing experience.
♦ We accept OEM. The cable size and material are customized.Ur own logo and
own design are welcome. We will produce according to your requirement and description;
♦ Please send us inquiry for more products info and we will give you feedback in 12 hours.
